| Number of Bus Terminals |
64 (255 with K-bus extension) |
| Max. number of bytes fieldbus |
16 Tx/Rx PDOs |
| Number of PDOs (CANopen) |
16 Tx/Rx PDOs |
| Additional CANopen features |
life, node guarding, emergency object, variable mapping, store/restore |
| Data transfer rates |
automatic detection up to 1 Mbaud |
| Bus interface |
open style connector, 5-pin |
| Power supply |
24 V DC (-15 %/+20 %) |
| Serial interface |
configuration interface |
| Diagnostics LED |
2 x power supply, 2 x K-bus, 2 x fieldbus |
| Current supply K-bus |
1750 mA |
| Weight |
approx. 100 g |
| Operating/storage temperature |
-25…+60 °C/-40…+85 °C |
| Relative humidity |
95 %, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. |
IP20/variable |
| Approvals/markings |
CE, UL, ATEX, IECEx |
| Ex marking |
ATEX:
II 3 G Ex nA IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc |
