EMERSON/艾默生 ASCO電磁閥 531系列電磁閥
SOLENOID VALVES
15/16 pilot operated, spool type
single/dual solenoid
aluminium body, 1/4, Namur and
Threaded style
FEATURES
• The "Namur" style spool valve have threaded port connection and Namur interface,
and "Threaded" style spool valve have threaded port connections
• All the exhaust ports of this spool valve are connectable, providing better
environmental protection, particularly recommended for sensitive areas such as
clean rooms, and applications in the pharmaceutical and food processing sectors
• The valve offers environmental protection against the ingress of liquids, dusts or any
other foreign matter (environmentally-protected construction)
• Can be externally piloted (external air pilot supply) to convert valve to zero minimum
operation by flipping a gasket
• Stainless steel manual operator as standard
STANDARD VOLTAGES
DC (=) : 24V
AC (~) : 110V - 120V - 220V - 240V / 50 - 60 Hz
